INPUT:
Voltage range Note.1 96-264VAC 120-370VDC
AC current 2.6A/115VAC 1.7A/230VAC
Frequency range 47-63Hz
Inrush current (max) 20A/115VAC 35A/230VAC
OUTPUT:
DC voltage (V) 24V
Efficiency 87%
Rated Current(A) 6.5A/230VAC 5.2A/115VAC
Rated power(W) 156W/230VAC 125W/115VAC
Voltage ADJ. range ±10%
Ripple & noise(max ) Note.2 150mVp-p
Voltage tolerange Note.4 ±1%
Line regulation ±0.5%
Load regulation ±1%
Setup， rise time 1500ms 60ms/230VAC 3000ms 60ms/115VAC(at full load)
Hold up time 16ms/230VAC 10ms/115VAC(at full load)
Status indicator Green LED
NOTE:
1.Derating may be needed under low input voltage.Please check the derating curve for more details.
2.Ripple & noise are measured at 20MHZ of bandwidth by using a “12”twisted pair-wire terminated with a 0.1uf & 47uf parallel
capacitor.
3.All parameters NOT specially mentioned are measured at 230VAC input,rated load and 25℃ of ambient temperature.
4.Tolerance:includes set up tolerance,line regulation and load regulation.
5.The ambient temperature derating of 3.5℃ /1000m with fanless models and of 5℃ /1000m with fan models for operating altitude
higher than 2000m(6500ft).
6.The power supply is considered a component which will be installed into a final equipment .The final equipment must be reconfirmed that is still meets EMC directives
7.Installation clearances:40mm on top,20mm on the bottom,5mm on the left and right side are recommended when loaded
permanently with full power,In case the adjacent device is a heat source,15mm clearance is recommended.
8.Hiccup mode at 90-100VAC,recovers automatically after fault condition is removed.
